MPO/MTP-LC Harness/Breakout Cable

MPO/MTP to LC Duplex Premium Breakout Harness Cable

Our MPO/MTP to LC Duplex Breakout Harness Cables (also known as Fanout or Transition Cables) are engineered for high-density, high-speed network migrations. They provide a seamless, reliable transition from multi-fiber MPO/MTP backbone trunk cables to standard LC duplex ports on switches, patch panels, and server interfaces. Fully optimized for 40G/100G/400G/800G transceiver connectivity, these factory-terminated assemblies maximize port density while ensuring superior optical performance.

Key Product Features

• High-Density Transition Efficiency: Spreads a single 8, 12, or 24-fiber MPO/MTP connector on one end into premium standard LC duplex connectors on the other, dramatically reducing cable congestion in equipment racks.

• LC Uniboot Option Available: The LC fanout side can be configured with premium 2.0mm LC Uniboot connectors, cutting cable bulk by an additional 50% to maximize vertical airflow and cooling efficiency.

• Customizable Fanout Configurations: Available in equal-length or customized staggered-length fanout legs, perfectly tailored to match line card geometries of major switch vendors (e.g., Cisco, Arista, Juniper).

• Elite Low-Loss Components: Built with premium grade ferrules to achieve standard loss (≤0.70 dB) or Elite Grade low loss (MPO ≤0.35 dB, LC ≤0.15 dB) to meet stringent optical power budgets.

• Ruggedized Mechanical Build: Fanout transition joints are fully molded to protect delicate internal splitter points, delivering a heavy-duty connector-to-cable pull strength of no less than 70 N.

• Advanced Fire Safety & Compliance: Encased in eco-friendly Low Smoke Zero Halogen (LSZH-3) or Plenum (OFNP) jackets, strictly compliant with international IEC 60332-3 risk standards.

Technical Performance Matrix
